Legend Fitness 3268-F4 Fusion 4 Jammer Arms Module

Legend Fitness strength equipment comes with the longest warranty in the strength industry thanks to their superior craftsmanship and materials:

Commercial Warranty:
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Frame: 15 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Bushings: 5 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Bearings: 5 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Pulleys: 5 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Wood: 1 year
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Foam: 1 year
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Other Hard Components: 1 year
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Soft Components: 90 days
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Upholstery: 90 days
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Wood: 2 years

The full warranty coverage and exclusion details can be found here under BlueCube: https://www.blueskyfitsupply.com/pages/warranty-information

All Legend Fitness equipment is custom built-to-order by hand in Knoxville, TN. This means your order is built specifically for you once it is placed.

There is currently a 16-18 weeks for any new Legend Fitness orders.

With very few exceptions, almost everything made by Legend Fitness can be manufactured in 30 different powder coat (steel) colors and 24 different pad (upholstery) colors.

Logos in the form of decals, laser engravings, and embroidery can also be added to most pieces of Legend Fitness equipment.

Legend Fitness equipment is engineered with as few potential fail points as possible.

Their equipment uses more welds than bolts wherever possible, since welds are significantly stronger. This design feature increases overall strength and rigidity while reducing the amount of assembly and maintenance each piece requires.

This piece arrives mostly welded and assembled. The remaining assembly involves bolting the module onto a MODULAR Series cage using the included hardware.

Legend Fitness produces the highest caliber of commercial grade strength equipment in the world, making it very easy to maintain. Typical maintenance includes:

1. Cables & Pulleys: Cables and pulleys are wear items that require regular inspection. Check cables for cracks, kinks, or ballooning, especially near pulleys, and inspect cable end fittings. Damaged cables can lead to injury, so replace them immediately if wear is detected. Pulleys should also be checked for surface damage, cracks, or faulty bearings. Excessive noise or vibration indicates a bad pulley. If any issues are found, stop using the machine and replace the damaged parts.
2. Frames: Inspect frames for cracks, corrosion, or rust. If any issues are found, remove the machine from service and contact a qualified fitness equipment technician.
3. Upholstery: Upholstery, like cables, wears with use and should be inspected for tears, rips, and cracks. While worn upholstery doesn’t require taking a machine out of service, it should be replaced to prevent bacteria buildup or potential scratches to users.

To learn more about what it takes to maintain Legend Fitness equipment, check out the Legend Fitness Owner's Manual.

The high quality materials and craftsmanship used to produce Legend Fitness strength makes cleaning the equipment very simple. This includes:

1. Cables & Fasteners: Check and adjust cable tension as needed at the movement arm. Ensure all nuts, bolts, and fasteners are tight. If tightening is required, apply Loctite Threadlocker 242 for added security.
2. Frames: Polish frames as needed with automotive or non-appliance wax to protect against corrosive fluids. Avoid harsh cleaners, chemicals, or abrasive materials.
3. Upholstery: Clean upholstery with a standard vinyl upholstery cleaner or lanolin-based hand cleaner to maintain its flexibility and prevent cracking. To restore shine, spray lightly with furniture wax, wait 30 seconds, and wipe with a clean white cloth. Avoid harsh chemicals and colored cloths that may transfer dye.
4. Guide Rods & Weight Stacks: Clean guide rods weekly by wiping off dust and dirt with a soft, dry cloth, then applying a silicone-based lubricant. Avoid oil-based lubricants, except WD-40. Weight stacks should also be wiped down and inspected for chips, which can be touched up with matte black paint or a permanent marker. For light rust, use WD-40 on a clean cloth. If you notice cracks or damage to the weights, place an “Out of Order” sign on the machine and contact us for a replacement.
5. Bearings: Linear bearing shafts must be regularly cleaned and lubricated for optimal performance. Check for rust and remove it with fine sandpaper or steel wool before cleaning. Wipe down the shafts with a clean, dry cloth to remove debris, then apply a thin layer of silicone-based spray lubricant or WD-40 using a cloth. Avoid over-applying, as excess lubricant can attract grime. Sealed bearing pivot points don't need lubrication but should be wiped with a dry cloth to remove dust. Ensure smooth movement during inspection.

To learn more about what it takes to clean Legend Fitness equipment, check out the Legend Fitness Owner's Manual.

Blue Sky Fitness Supply will process your order within 24 hours of receiving it.

Once your order is processed, it will go into production where it is built-to-order.

Upon completing your order, it will be packaged and shipped. The transit time upon shipment is typically 3-5 days.

Once the shipment goes out and tracking information becomes available, it will be sent to you so you can track the shipment from door to door. You will also be contacted to schedule the time/day of delivery.

Our full shipping policy can be found below, and the current lead time is: 16-18 weeks

https://www.blueskyfitsupply.com/pages/shipping-policy

Blue Sky Fitness Supply requests that customers who wish to return purchased goods for any reason after receiving a delivery contact us within 30 days of placing the order to request a return. Return requests made outside of 30 days may not be approved.

In the event of returning an item, you will be responsible for the return shipping costs in addition to being assessed a 20% restocking fee.

Our full return and refund policy can be found here under Spirit Fitness: https://www.blueskyfitsupply.com/pages/return-and-refund-policy

Legend Fitness has been crafting top-tier commercial gym equipment for over 40 years, and they’ve never been afraid to do things a little differently. From their headquarters in Knoxville, Tennessee, Legend Fitness focuses on building gym equipment which is built to last and built to preference thanks to their dozens of customization options. With a reputation for quality among high schools, colleges, professional sports teams, and gyms, their strength and fitness equipment is known for durability and precision.

One of the standout features of Legend Fitness is their commitment to keeping production in-house. Everything from cutting and welding American steel to stitching upholstery is done in their Knoxville facility. This hands-on approach allows Legend Fitness to maintain top quality across every product, from power cages to utility benches. Their attention to detail even extends to shipping, where they build custom containers for certain products to ensure they arrive in perfect condition.

What really sets Legend Fitness apart is their made-to-order philosophy. Each piece of equipment is crafted specifically for the buyer, with a range of personalization options that includes over 30 powder coat colors and more than 80 upholstery choices. Whether outfitting a high school gym or a professional training facility, customers can match their gear to team colors or logos with ease. Plus, with options like custom embroidery and logo decals, Legend Fitness ensures each piece is as unique as the client’s brand.

While personalization is key, strength and safety are Legend Fitness’s primary focus. Built using 11-gauge American steel, their equipment is designed to withstand heavy daily use without compromising on performance. Investing in Legend Fitness strength equipment means choosing durability and reliability that lasts.

Blue Sky Fitness Supply is proud to partner with Legend Fitness to bring their exceptional, American-made gym equipment to customers. Each piece is designed with the end-user in mind, offering exceptional durability, extensive customization, and great value. When you choose Legend Fitness through Blue Sky Fitness Supply, you’re choosing quality that stands the test of time.
