Spirit Fitness CSS-LATP Lat Pulldown

Yes — the CSS-LATP is a dedicated single-station lat pulldown built to Spirit's Commercial grade, with a fully enclosed 250 lb weight stack and a direct 1:1 pulley ratio through LOOS USA cables.

The CSS-LATP is part of Spirit Fitness's Selectorized line — single-station machines that isolate one movement rather than combining two exercises on one frame. It trains lat pulldown exclusively, with a fully enclosed 250 lb weight stack moving in 5 lb increments through a direct 1:1 pulley ratio and LOOS USA cables, so the full stack weight is felt at the bar. The frame is commercial-grade steel finished in electrostatic powder coat, low-profile enough to keep sightlines open across a gym floor, and rated for a 360 lb max user weight. Spirit backs the CSS-LATP with its Commercial warranty tier, including a 10-year frame term, the same coverage standard used across its combo and dual machines.

It ships free via LTL freight across multiple cartons with liftgate delivery included by default, and Spirit Fitness recommends at least two people for assembly.

The CSS-LATP ships free by LTL freight, arriving disassembled across several cartons per Spirit Fitness's packing spec, with liftgate delivery included by default so the crates come off the truck without a dock or forklift. If you have a loading dock or forklift on-site, ask for a no-liftgate freight quote to save on the delivery cost. Each shipment includes a full illustrated owner's manual along with every tool and piece of hardware needed for setup, and Spirit Fitness recommends at least two people handle assembly. Professional installation is also available through Blue Sky Fitness Supply if you'd rather not assemble it yourself.

Contact Blue Sky Fitness Supply first — we handle the warranty claim and coordinate with Spirit Fitness's service network to source the replacement part, so you're not navigating it alone.

If any part of the CSS-LATP ever needs service, Blue Sky Fitness Supply handles the claim on your behalf and coordinates directly with Spirit Fitness's authorized service network to source the replacement. All repairs must be preauthorized before any work begins. Spirit Fitness's own service department is also reachable directly if you'd rather coordinate yourself, but it's never required — Blue Sky manages the process either way. Warranty registration must be completed online within 10 days of delivery to validate coverage, so keep your bill of sale and register promptly after the machine arrives.

A 10-year term covers the frame, welds, cams & plates; 5 years covers bushings, bearings, shocks, pulleys & guide rods; and 1 year covers finishes, cables, grips & labor.

Spirit Fitness backs the CSS-LATP with a Commercial warranty covering every functional component. The frame, welds, cams, and plates carry a 10-year term, while bushings, bearings, shocks, pulleys, and guide rods are covered for 5 years. Paint and finishes, cables, grips, the counter/timer, pull-pin components, rail wheels, attachments, and all other parts carry a 1-year term, upholstery is covered for 6 months, and general labor runs 1 year. Registration must be completed online within 10 days of delivery to validate coverage, and prisons or correctional facilities are excluded.

It's built for users from 4'11" to 6'8" up to 360 lb, with adjustable chain-links for bar height and adjustable thigh pads that lock the lower body in place.

Spirit Fitness recommends the CSS-LATP for users from 4'11" to 6'8" tall, rated up to a 360 lb max user weight — a range that covers the vast majority of a commercial membership base. Adjustable chain-links let a user set the bar at a comfortable starting height for their own reach, while adjustable thigh pads lock the lower body in place so heavy pulls don't lift a user off the seat mid-rep. That combination of bar-height and thigh-pad adjustment makes the CSS-LATP workable across a broader range of heights and pulling styles than a fixed setup would allow.

A fully enclosed 250 lb weight stack moves in 5 lb increments, set with a pop-pin selector, and a direct 1:1 pulley ratio through LOOS USA cables means the full stack weight is felt right at the bar.

The CSS-LATP uses a classic pin-select system: a fully enclosed 250 lb weight stack, built from a 10 lb top plate plus 8x10 lb plates and 8x20 lb plates, lets a user set resistance in clean 5 lb increments by moving a single selector pin. Unlike some Spirit Selectorized machines that use a reduced pulley ratio, the CSS-LATP runs a direct 1:1 pulley ratio, so the number on the weight stack is the resistance felt at the bar — no mechanical reduction — routed through LOOS USA cables chosen for their low stretch and long service life under repeated use. Because the stack is fully enclosed, there's no exposed cable or moving plate for a user to catch a finger on between sets.

The CSS-LATP targets the latissimus dorsi and upper back, the muscles responsible for pulling the arms down and back — a staple movement for back width, posture, and pulling strength.

Lat pulldown is a pulling movement that trains the latissimus dorsi across the sides of the back, along with supporting muscles in the upper back, shoulders, and arms that assist in pulling the bar down. It's one of the most common back-building exercises in any strength program, valued for building back width and improving pulling strength and posture without requiring the grip strength or setup a pull-up demands. The adjustable chain-link bar height and thigh pads on this specific machine make it workable for a wider range of user heights and pulling stances than a fixed-height station would allow.

Yes — the CSS-LATP occupies about 58" L × 47.8" W and stands 91" tall, with a low-profile frame designed to keep sightlines open across the room.

The CSS-LATP occupies about 58 inches long by 47.8 inches wide and stands 91 inches tall, with a low-profile frame designed to keep sightlines open across a busy gym floor. As a single-station machine, it does one job — lat pulldown — rather than combining two exercises on one frame the way Spirit's dual machines do, which makes it a straightforward fit for a facility building out a full circuit of dedicated single-movement stations. Steel feet with rubber covers keep the 515.7 lb frame stable and floor-safe once it's assembled. For a facility planning a back-day circuit, the CSS-LATP's compact, low-profile footprint is an easy complement to a low row or seated row station nearby.

Commercial Warranty:
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Frame: 10 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Bushings / Bearings / Pulleys: 5 years
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Other parts: 1 year
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Upholstery: 6 months
‎ ‎ ‎ ‎ ‎ ‎ ●‎‎ ‎ ‎ Labor: 1 year https://www.blueskyfitsupply.com/pages/warranty-information
